| Category | Specification |
|---|---|
| Form Factor | 4U Rack Server |
| Dimensions (H × W × D) | 174.4 mm × 447.4 mm × 828 mm |
| Processor | Up to 2 × Intel Scalable processors or Montage Jintide processors |
| CPU Cores | Up to 64 cores per processor |
| Max CPU Power | 350W |
| Memory Slots | Up to 32 DIMM slots |
| Memory Type | DDR5 RDIMM |
| Memory Speed | Up to 5600 MT/s |
| GPU Support | Up to 2 dual-width GPUs or 6 single-width GPUs |
| Storage Bays | Up to 44 × 3.5" drive bays |
| NVMe Support | Up to 16 NVMe U.2 SSDs |
| Front Storage | Up to 24 × 3.5" hot-swappable drives |
| Middle Storage | 4 × 3.5" drives (optional, non hot-swappable) |
| Rear Storage | Up to 12 × 3.5" hot-swappable drives |
| Additional Rear Storage | Optional 4 × 3.5" hot-swappable drives |
| Optional Rear NVMe | Up to 10 × 2.5" hot-swappable NVMe drives |
| Boot Storage | Internal SATA / NVMe M.2 slot |
| Storage Controller | HBA controller or RAID controller (RAID 0/1/5/6/10/50/60) |
| NVMe RAID | Supported via Intel VROC |
| PCIe Expansion | Up to 6 full-height cards and 4 half-height cards |
| OCP Slots | 2 × OCP 3.0 slots |
| Management | AST2600 BMC with IPMI 2.0, Redfish, SOL, KVM, Virtual Media |
| Networking | 1 × dedicated GbE management port, OCP NIC support |
| I/O Ports | RJ45 management port, VGA port, 4 × USB ports |
| Security | Chassis intrusion detection, Intel PFR 3.0, SGX 2.0, TPM/TCM |
| Power Supply | 800W / 1300W / 1600W / 2000W / 2600W / 2700W / 3200W CRPS PSU |
| Power Redundancy | 1+1 redundancy |
| Operating Temperature | 0°C – 35°C |
