48GE(POE)+6*10G SFP+ L3 managed high-power PoE switch

Name: 48GE(POE)+6*10G SFP+ L3 managed high-power PoE switch
Brand: portower
Price: 999.00 USD
Availability: InStock

$999.00

Sale Sold out

Shipping calculated at checkout.

Overview

Support static aggregation and dynamic aggregation (LACP) mode, effectively increase link bandwidth, improve link reliability, and realize load balancing and link backup
Flexible and convenient management and maintenance, support Console, Telnet, SSH, and other management methods;
Support WEB management, more simple and efficient, easy to install and debug engineering and maintenance personnel;
Support HTTP/TFTP/FTP file upload and download management;
Control of three-layer routing protocol, adapt to multiple services, efficient and guaranteed information transmission;
IP dynamic routing protocol supports RIP, OSPFv2, IPv4/IPv6 static routing;
Automatic detection and identification of standard PoE powered equipment, intelligent power supply, prevent the burning of non-standard PoE powered equipment or ordinary equipment;
Fan speed control, adjust the fan speed according to the real-time temperature of the machine, to achieve noise control under different working conditions
Support port power supply priority to ensure continuous power supply of key network nodes;

View full details

PM9054GTM-6F8HP-V2 is a L3 managed high-power PoE switch developed by our company, which provides 48 10M/100M/1000Mbps adaptive RJ45 ports, 6 1G/2.5G/10Gbps SFP+ optical fiber module expansion slots, 1 Console port and 1*USB port, Each RJ45 port uses store-and-forward technology, combined with dynamic memory allocation, to ensure efficient bandwidth allocation to each port. Ports 1-48 have PoE power supply function, among which ports 1-8 support IEEE802.3af/at/bt standard, maximum power up to 90W, and ports 9-48 support IEEE802.3af/at standard, maximum power up to 30W. Designed for building high-performance enterprise networks, it is able to leverage PoE++ (802.3af/at/bt) technology to build redundant, secure and highly reliable video surveillance and WiFi networks, as well as government information system networks and other application networks that require improved reliability, security and performance.

Model	PM9054GTM-6F8HP-V2
Interface	4810/100/1000Mbps RJ45 Ports 61G/2.5Gbps SFP+ fiber module expansion slot 1Console Port 1USB port
Standard	IEEE802.3, IEEE802.3a, IEEE802.1ab, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.1q, IEEE802.1p, IEEE802.1x, IEEE802.1s, IEEE802.1d, IEEE802.1w, IEEE802.3ad, IEEE802.3af, IEEE802.3at, IEEE802.3bt
Network media(cable)	10BASE-T: UTP category 3,4,5 cable (≤100m) 100BASE-TX: UTP category 5, 5e cable (≤100m) 1000BASE-T: UTP category 5e, 6 cable (≤100m) 1000BASE-X: MMF, SMF modules 10GBASE-X: indicates the MMF module 10GBASE-SR: OM1/OM2/OM3 or higher MMF (2m ~ 300m) 10GBASE-LR: IEC B1.1 and B1.3 SMF (2m ~ 10000m)
Indicator	PWR (green), LNK/ACT (green), SYS (green), PoE (yellow)
MAC Address Table	32K, Auto-learning, Auto-update
Jumbo Frame	12KBytes
Packet Buffer	16Mbit
Transfer Mode	Store-and-forward
Switching Capacity	216Gbps
Packet Forward Speed	160.7Mpps
Dimensions(LWH)	44033044mm
Total Power Supply	1000W
Input voltage	AC：100-240V，50/60Hz
PoE Total Power	750W
PoE Port	Ports 1-48
PoE Output Power	1-8 Ports:90W 9-48 Ports: 30W
PoE Power On RJ45	1-8 Ports: 1/2(-), 3/6(+), 4/5(+),7/8(-) 9-48 Ports: 1/2(-), 3/6(+)
Operating Temperature	0°C ~ 50°C
Storage Temperature	-40°C ~ 70°C
Operating Humidity	10% ~ 90% non-condensing
Storage Humidity	5% ~ 90% non-condensing
Lightning protection class	Common mode ±6KV, Differential mode ±4KV
Electrostatic Standard	Contact ±6KV, Air ±8KV
MTBF	>50000 hours

L3 Features	DHCP Server	DHCP Server
	DHCP Server	DHCPv6 Server
	Route	Static Route(IPV4/IPV6)
	Route	Route Aggregation
	RIP	RIP v1/v2/RIPng
	OSPF	OSPF v2/v3
	BGP	BGP4/BGP6
	VRRP	IPv4/IPv6 VRRP
	PIM	IPv4/IPv6 PIM
	Stacking	Stacking VSF
L2 Features	MAC Address Table	MAC Aging Time
		MAC Filter
		MAC Notification
	Basic Management	Console/Telnet/SSH
		Http/Https、SSL/TLS
		FTP/TFTP
		Syslog
		SNMP(v1/v2c/v3)、SNMP Trap
		RMON
		SNTP/NTP
		CPU protect
		Software/Hardware watchdog
		Firmware Upgrade/Backup
		Ping/Traceroute
		Onvif
		ZTP
	Port Config	Bandwidth Control
		Flow Control
		EEE
		MTU
		CFM(802.1ag)
		EFM OAM(802.3ah)
		DDM
		Storm Control
		Port Isolation
		Port Security
		Virtual Cable Test
		ULDP/Cisco UDLD
	Discovery	LLDP(802.1ab)
	Discovery	LLDP-MED
	Link Aggregation	Static
		LACP(802.3ad)
		Load Balance(src-mac/dst-mac/src-ip/dst-ip)
		Max groups and ports per group
	VLAN	VLAN(802.1Q 4K)
		Access/Trunk/Hybrid
		Private VLAN
		VLAN Filter
		MAC-based VLAN
		Protocol-based VLAN
		IP Subnet-based VLAN
		Voice VLAN
		GVRP/GMRP
		QinQ/Selective-QinQ/Flexible QinQ
		VLAN Translation/N:1 VLAN Translation
		Guest VLAN
	Network Loop Detection	Loopback Detection
	Network Loop Detection	ERPS
	Spanning Tree	STP/RSTP/MSTP
		MSTP Support 64 instance
		BPDU Guard/Root Guard/BPDU Tunnel
	ARP	Static ARP
		ARP Scanning Prevention
		ARP Spoofing Prevention
		ARP Guard
		Gratuitous ARP
		Dynamic ARP Inspection
		ARP Quantity Control
IPv4 Related Function	ICMP	Anti ICMP Attack
		ICMP Rate Limit
		ICMP Unreachable Drop
	Control Multicast	DCSCM
	Multicast VLAN	Multicast VALN
	IGMP	IGMP SNOOPING V1/V2/V3
		Fast Leave
		IGMP Proxy
	DHCP	DHCP Client/BOOTP
		DHCP Relay
		DHCP Snooping
		DHCP Option 82/43/60/61/67
IPv6 Related Function	IPv6 Basic	IPv6 ND Snooping
	DHCPv6	DHCPv6 Relay
		DHCPv6 Snooping
		IPv6 SAVI
		Security RA
		MLD v1/V2 Snooping
	IPv6 Features	SNMP over IPv6 Support
		HTTP over IPv6 Support
		SSH over IPv6 Support
		DNS over IPv6 Support
		IPv6 ping/traceroute Support
		IPv6 Telnet Support
		IPv6 Radius+ Support
		IPv6 Tacacs+ Support
		IPv6 SNTP/NTP Support
		IPv6 FTP/TFTP Support
		IPv6 IPSec Support
		IPv6 ACL
QoS(Quality Of Service)	Basic	Trust COS/DSCP
	Basic	Trust Port
	Scheduling	SP
		WRR
		WDRR
	PolicyMap Stream	Based on VLAN
		Based on COS/DSCP
		Aggregate PolicyMap
		Ingress PolicyMap
	Policing	CAR Stream Shaping(leak algorithm)
	Policing	Ingress Policing
	Rewrite	COS/802.1p Priority
		IP Precedence
		IPv4 DSCP/IPv6 DSCP
		drop-precedence
		internal-priority
		Ingress/Egress Rewrite
	Queuing	DSCP to DSCP mapping
		DSCP to DP mapping
		DSCP to Queue mapping
		COS to DP mapping
		COS to Queue mapping
ACL	IP-ACL	SIP/DIP
		IP Protocol
		IP Priority(DSCP,TOS, Precedence)
		TCP,UDP src,dst Port
	MAC-ACL	SRC/DST MAC
		VLAN
		COS
		Tag/Untag
	IP-MAC ACL	MAC-ACL and IP-ACL
	User-defined ACL	Base on user defined profile
	ACL Features	Based on time period ACL
		ACL on VLAN
		Based on ACL Stream
Security	802.1x	Port Based Authentication
		Support EAPoR
		MAC based Authentication
		Guest VLAN
	MAB	Based on Port Authentication
	MAB	Based on MAC Authentication
	MAC Address Count Limit	Based on Port
	MAC Address Count Limit	Based on VLAN
	IP Address Count Limit	Based on Port
	IP Address Count Limit	Based on VLAN
	Access Management	Based on source mac and IP address
	Deny DoS Attack	TCP Flag
		TCP Flagment
		IP Segment
		ICMP
	TACACS+	Standard Support
	Radius	Standard Support
	Radius	Client, Support MD5
	SSL	Openssl 1.1.0
Redundancy Related Function	MRPP	Compatiable ERRP
	ULPP	Uplink Protection Protocol
	ULPP	Smart Link/Monitor Link
	ULSM	Uplink State Monitor
Flow Monitor Function	Mirror	Support one to one, multi to one
		Port based mirror, support ingress, egress, and both
		CPU based mirror
		Flow based mirror
		RSPAN
PoE	PoE Management	ON/OFF Config
		Alive Checking for PD
		7/24 On/Off Scheduling
